main.cpp
timer.cpp timer.h -> timer.ui
clockthread.cpp clockthread.h
TBD
- 마우스 좌표로 프로그램 위치 옮기기
- 메뉴바 없애기
- pause 동작하기
main.cpp
#include "timer.h"
#include <QtWidgets/QApplication>
int main(int argc, char *argv[])
{
QApplication a(argc, argv);
timer w;
w.show();
return a.exec();
}
timer.h
#pragma once
#ifndef TIMER_H
#define TIMER_H
#include "clockthread.h"
#include <QtWidgets/QMainWindow>
#include "ui_timer.h"
class ClockThread;
class timer : public QMainWindow
{
Q_OBJECT
public:
timer(QWidget *parent = Q_NULLPTR);
private:
Ui::timerClass ui;
ClockThread m_clockThread;
signals:
void reset();
private slots:
void on_closeButton_clicked();
void on_startButton_clicked();
void on_pauseButton_clicked();
void on_resetButton_clicked();
};
#endiftimer.cpp
#include "timer.h"
/**
*/
timer::timer(QWidget *parent)
: QMainWindow(parent)
{
ui.setupUi(this);
setWindowFlags(Qt::Widget | Qt::FramelessWindowHint);
setParent(0); // Create toplevel widget -> ?
setAttribute(Qt::WA_NoSystemBackground, true);
// 위젯이 배경이 없는 것을 나타낸다.
// 위젯이 paint Event를 받을 때, 배경이 자동적으로 다시 그려지지 않는다.
// WA_OpaquePaintEvent와는 다르게, 새로 노출된 부분이 절대 배경으로 채워지지 않는다.
// WA_OpaquePaintEvent : 윈도우가 처음에 보여진 이후에, 프로그램이 paint event를 동작시킬 때까지 이것을 통해 user는 볼 수 있다.
setAttribute(Qt::WA_TranslucentBackground, true);
// 위젯이 투명한 배경을 가져야만 한다.
// 위젯의 불투명하지 않은 부분이 투명해진다. 왜냐하면 위젯이 alpha 채널을 가지고 잇기 때문이다.
// WA_TranslucentBackground 플래그를 셋팅하는 것은 WA_NoSystemBackground를 셋팅하도록 만든다.
// 또한 윈도우에서 실행되는 프로그램이라면 Qt::FramelessWindowHint 플래그도 설정해야한다.
setAttribute(Qt::WA_PaintOnScreen);
setFixedSize(600,240);
connect(&m_clockThread, SIGNAL(sendTime(QString)), ui.label, SLOT(setText(QString)), Qt::QueuedConnection);
connect(this, SIGNAL(reset()), &m_clockThread, SLOT(onReset()));
}
/**
*/
void timer::on_closeButton_clicked()
{
//ui.label->setText("clicked closeButton");
}
/**
*/
void timer::on_startButton_clicked()
{
//ui.label->setText("clicked startButton");
m_clockThread.start();
}
/**
*/
void timer::on_pauseButton_clicked()
{
//ui.label->setText("clicked pauseButton");
m_clockThread.wait(); // 파라미터 ULONG_MAX 줘야하는건지?
}
/**
*/
void timer::on_resetButton_clicked()
{
//ui.label->setText("clicked resetButton");
emit reset();
}timer.ui
<?xml version="1.0" encoding="UTF-8"?>
<ui version="4.0">
<class>timerClass</class>
<widget class="QMainWindow" name="timerClass">
<property name="geometry">
<rect>
<x>0</x>
<y>0</y>
<width>600</width>
<height>237</height>
</rect>
</property>
<property name="windowTitle">
<string>timer</string>
</property>
<widget class="QWidget" name="centralWidget">
<widget class="QWidget" name="gridLayoutWidget">
<property name="geometry">
<rect>
<x>10</x>
<y>4</y>
<width>581</width>
<height>151</height>
</rect>
</property>
<layout class="QGridLayout" name="gridLayout">
<item row="2" column="1">
<widget class="QPushButton" name="pause">
<property name="text">
<string>pause</string>
</property>
</widget>
</item>
<item row="1" column="0" colspan="3">
<widget class="QLabel" name="label">
<property name="sizePolicy">
<sizepolicy hsizetype="Expanding" vsizetype="Expanding">
<horstretch>0</horstretch>
<verstretch>0</verstretch>
</sizepolicy>
</property>
<property name="text">
<string>TextLabel</string>
</property>
<property name="alignment">
<set>Qt::AlignCenter</set>
</property>
</widget>
</item>
<item row="2" column="0">
<widget class="QPushButton" name="startButton">
<property name="text">
<string>start</string>
</property>
</widget>
</item>
<item row="2" column="2">
<widget class="QPushButton" name="resetButton">
<property name="text">
<string>reset</string>
</property>
</widget>
</item>
<item row="0" column="2">
<widget class="QPushButton" name="closeButton">
<property name="sizePolicy">
<sizepolicy hsizetype="Minimum" vsizetype="Minimum">
<horstretch>0</horstretch>
<verstretch>0</verstretch>
</sizepolicy>
</property>
<property name="text">
<string>close</string>
</property>
</widget>
</item>
</layout>
</widget>
</widget>
<widget class="QMenuBar" name="menuBar">
<property name="geometry">
<rect>
<x>0</x>
<y>0</y>
<width>600</width>
<height>26</height>
</rect>
</property>
</widget>
<widget class="QToolBar" name="mainToolBar">
<attribute name="toolBarArea">
<enum>TopToolBarArea</enum>
</attribute>
<attribute name="toolBarBreak">
<bool>false</bool>
</attribute>
</widget>
<widget class="QStatusBar" name="statusBar"/>
</widget>
<layoutdefault spacing="6" margin="11"/>
<resources>
<include location="timer.qrc"/>
</resources>
<connections/>
</ui>
clockthread.cpp
#include "clockthread.h"
#include <QTimer>
ClockThread::ClockThread(QObject* parent)
: QThread(parent)
{
init();
}
ClockThread::~ClockThread()
{
}
void ClockThread::init()
{
m_hours = 0;
m_minutes = 0;
m_seconds = 0;
}
void ClockThread::onReset()
{
}
void ClockThread::run()
{
QTimer timer;
connect(&timer, SIGNAL(timeout()), this, SLOT(timerHit()), Qt::DirectConnection);
timer.setInterval(1000); // 1000msc = 1 sec
timer.start();
exec();
}
void ClockThread::timerHit()
{
m_seconds++;
if(m_seconds>60)
{
m_minutes++;
m_seconds = 0;
}
if(m_minutes>60)
{
m_hours++;
m_minutes = 0;
}
QString time = QString("%1:%2:%3").arg(m_hours).arg(m_minutes).arg(m_seconds);
emit sendTime(time);
}clockthread.h
#ifndef CLOCKTHREAD_H
#define CLOCKTHREAD_H
#include <QThread>
#include <QObject>
class ClockThread : public QThread
{
Q_OBJECT;
public:
ClockThread(QObject* parent=Q_NULLPTR);
virtual ~ClockThread();
private:
int m_hours;
int m_minutes;
int m_seconds;
private:
void init();
void run();
signals:
void sendTime(QString time);
private slots:
void onReset();
void timerHit();
};
#endif
